Acousto-optic modulator is commonly used to adjust laser intensity (amplitude modulation, AM) outside the laser cavity.
Classification:
Detailed introduction
Acousto-optic modulator is commonly used to adjust laser intensity (amplitude modulation, AM) outside the laser cavity.
Application
Chopper
Laser radar
Laser switch
Intensity modulation
Laser precision machining
Standard products（Customized available）
Wavelength | Active Aperture | Operating Frequency | Loss Modulation | Optical Material | Cooling |
| 532nm | 3mm | 110MHz | ＞85% | Crystalline quartz | Conduction-cooled |
| 355nm | 6mm | 170MHz | ＞85% | Crystalline quartz | Water-cooled |
| 343nm | 6mm | 110MHz | ＞85% | Crystalline quartz | Water-cooled |
| 266nm | 3.5mm | 200MHz | ＞85% | Crystalline quartz | Conduction-cooled |
| 800nm | 1mm | 100MHz | ＞85% | Crystalline quartz | Conduction-cooled |
| 9600nm | 8mm | 40.68MHz | ＞80% | Germanium | Water-cooled |
| 780nm | 3mm | 68MHz | ＞85% | Crystalline quartz | Conduction-cooled |
| 266nm | 6mm | 200MHz | ＞85% | Crystalline quartz | Water-cooled |
| 10600nm | 8mm | 40.68MHz | ＞80% | Germanium | Water-cooled |
